Toyota Kluger I (XU20) SUV 5 doors All photos (4)
Toyota Kluger I (XU20) · SUV 5 doors · 2000–2003

Toyota Kluger 2.4 AT 160 HP

DieselAutomatic, 4 gearsFront drive
Power
135 hp · 99 kW
Torque
309 Nm
0–100 km/h
14.5 s
Top speed
166 km/h
Fuel consumption
9.5 l/100 km
On a full tank
~790 km
Other versions of this body · 4
2.4 AT 160 HP 2.4 AT 160 HP AWD 3.0 AT 220 HP 3.0 AT 220 HP AWD

Consumption and performance

manufacturer data
Top speed
166 km/h
Acceleration 0–100 km/h
14.5 s
Fuel tank
75 l

Engine

J3 · 2,903 cm³
Engine type
Diesel
Engine code
J3
Displacement
2,903 cm³
Max power
99 kW / 135 hp
Torque
309 Nm at 2000 rpm
Fuel system
Diesel
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
97.1 mm
Stroke
98 mm
Compression ratio
19

Transmission

Drive
Front
Gearbox
Automatic
Gears
4

Dimensions and capacity

class M
Body type
Minivan
Doors
5
Seats
5, 7
Length
4,890 mm
Width
1,900 mm
Height
1,730 mm
Wheelbase
2,905 mm
Front track
1,635 mm
Rear track
1,600 mm
Ground clearance
170 mm
Boot space (min)
2,000 l
Boot space (max)
2,000 l

Wheels, brakes and chassis

Tyre size
205/70/R15
Wheel fitment (PCD, CB)
DIA67.1 5x114.3
Front brakes
Discs
Rear brakes
Drums
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
