Toyota Grand HiAce I I Minivan All photos (3)
Toyota Grand HiAce I I · Minivan · 1999–2002

Toyota Grand HiAce I 3.0 AT 140 HP

DieselManual, 6 gearsAll driveEuro 4
Power
200 hp · 147 kW
Torque
410 Nm
0–100 km/h
10.5 s
Other versions of this body · 7
3.0 AT 140 HP 3.0 AT 140 HP AWD 3.0 MT 140 HP 3.4 AT 180 HP 3.4 AT 180 HP AWD 3.4 MT 180 HP All versions →

Consumption and performance

manufacturer data
Acceleration 0–100 km/h
10.5 s
Fuel tank
70 l

Engine

vm a 428 dohc · 2,778 cm³
Engine type
Diesel
Engine code
vm a 428 dohc
Displacement
2,778 cm³
Max power
147 kW / 200 hp
Torque
410 Nm at 2000 rpm
Fuel system
Diesel, Common rail
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
94 mm
Stroke
100 mm
Compression ratio
17.5
Emission standard
Euro 4

Transmission

Drive
All
Gearbox
Manual
Gears
6

Dimensions and capacity

Body code KK · class J
Body type
SUV
Doors
5
Seats
5
Length
4,493 mm
Width
1,839 mm
Height
1,736 mm
Wheelbase
2,694 mm
Front track
1,549 mm
Rear track
1,549 mm
Ground clearance
190 mm
Kerb weight
1,980 kg
Max weight
2,520 kg
Boot space (min)
419 l
Boot space (max)
1,404 l

Wheels, brakes and chassis

Tyre size
235/65/R17 235/60/R18
Wheel fitment (PCD, CB)
DIA71.5 5x114.3
Wheel tightening torque
130 Nm
Tyre pressure
2.2-2.3 bar
Front brakes
Ventilated discs
Rear brakes
Ventilated discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
