Renault Kangoo II Facelift Minivan Grand All photos (3)
Renault Kangoo II Facelift · Minivan Grand · 2013–2021

Renault Kangoo Grand 1.5 MT 110 HP

GasolineAutomatic, 5 gearsFront driveEuro 5
Power
139 hp · 102 kW
Torque
191 Nm
Top speed
175 km/h
Fuel consumption
8.6 l/100 km
On a full tank
~700 km
Other versions of this body · 2
Grand 1.5 MT 110 HP Grand 1.5 MT 90 HP

Consumption and performance

manufacturer data
Top speed
175 km/h
Fuel tank
60 l

Engine

JLD4G20 · 1,997 cm³
Engine type
Gasoline
Engine code
JLD4G20
Displacement
1,997 cm³
Max power
102 kW / 139 hp
Torque
191 Nm at 4000 rpm
Fuel
A95
Fuel system
Multipoint injection
Turbo
No
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
86 mm
Stroke
86 mm
Compression ratio
9.5
Emission standard
Euro 5

Transmission

Drive
Front
Gearbox
Automatic
Gears
5

Dimensions and capacity

class J
Body type
SUV
Doors
5
Seats
5
Length
4,540 mm
Width
1,834 mm
Height
1,707 mm
Wheelbase
2,661 mm
Front track
1,560 mm
Rear track
1,560 mm
Ground clearance
171 mm
Kerb weight
1,615 kg
Max weight
1,915 kg
Boot space (min)
580 l
Boot space (max)
580 l

Wheels, brakes and chassis

Tyre size
225/65/R17
Optional tyre sizes
225/60R18
Wheel fitment (PCD, CB)
DIA60.1 5x114.3
Wheel fasteners
Nuts M12x1.5
Wheel tightening torque
100-120 Nm
Tyre pressure
2.3 bar
Front brakes
Discs
Rear brakes
Discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
