Mercedes-Benz S class IV (W220) Limousine Pullman All photos (4)
Mercedes-Benz S class IV (W220) · Limousine Pullman · 1998–2005

Mercedes-Benz S class Pullman 5.0 AT 306 HP

GasolineAutomatic, 5 gearsRear drive
Power
306 hp · 225 kW
Torque
460 Nm
0–100 km/h
6.5 s
Top speed
250 km/h
Fuel consumption
11.9 l/100 km
On a full tank
~740 km
Other versions of this body · 3
Pullman 5.0 AT 306 HP Pullman 5.5 AT 500 HP Pullman 5.8 AT 367 HP

Consumption and performance

manufacturer data
Top speed
250 km/h
Acceleration 0–100 km/h
6.5 s
Fuel tank
88 l

Engine

M113.961 · 4,966 cm³
Engine type
Gasoline
Engine code
M113.961
Displacement
4,966 cm³
Max power
225 kW / 306 hp
Torque
460 Nm at 2700 rpm
Fuel
A95
Fuel system
Multipoint injection
Turbo
No
Engine position
V type
Cylinders
8
Valves per cylinder
3
Valvetrain
OHC
Bore
97 mm
Stroke
84 mm
Compression ratio
10

Transmission

Drive
Rear
Gearbox
Automatic
Gears
5

Dimensions and capacity

class F
Body type
Limousine
Doors
4
Seats
6
Length
6,158 mm
Width
1,855 mm
Height
1,462 mm
Wheelbase
4,085 mm
Front track
1,575 mm
Rear track
1,575 mm
Ground clearance
150 mm
Kerb weight
1,855 kg
Max weight
2,400 kg
Boot space (min)
500 l
Boot space (max)
500 l

Wheels, brakes and chassis

Tyre size
225/60/R16
Optional tyre sizes
245/45R18 / 265/40R18, 245/45R18 / 275/40R18, 255/40R19 / 285/35R19
Rim size
8jx18
Wheel fitment (PCD, CB)
DIA66.6 5x112
Front brakes
Ventilated discs
Rear brakes
Ventilated discs
Front suspension
Independent, air suspension
Rear suspension
Independent, air suspension
