Mercedes-Benz S class IV (W220) Facelift · Sedan · 2002–2006
Mercedes-Benz S class 320 3.2 AT 204 HP
- Power
- 204 hp · 150 kW
- Torque
- 500 Nm
- 0–100 km/h
- 8.2 s
- Top speed
- 235 km/h
- Fuel consumption
- 7.9 l/100 km
- On a full tank
- ~1,110 km
Other versions of this body · 10
Consumption and performance
- Top speed
- 235 km/h
- Acceleration 0–100 km/h
- 8.2 s
- Fuel tank
- 88 l
Engine
- Engine type
- Diesel
- Engine code
- OM648.960
- Displacement
- 3,222 cm³
- Max power
- 150 kW / 204 hp
- Torque
- 500 Nm at 1800 rpm
- Fuel system
- Diesel, Common rail
- Turbo
- Turbo
- Engine position
- In front
- Cylinders
- 6
- Valves per cylinder
- 4
- Valvetrain
- DOHC
- Bore
- 88 mm
- Stroke
- 88.3 mm
- Compression ratio
- 18
Transmission
- Drive
- Rear
- Gearbox
- Automatic
- Gears
- 5
Dimensions and capacity
- Body type
- Sedan
- Doors
- 4
- Seats
- 5
- Length
- 5,042 mm
- Width
- 1,855 mm
- Height
- 1,448 mm
- Wheelbase
- 2,965 mm
- Front track
- 1,575 mm
- Rear track
- 1,575 mm
- Ground clearance
- 150 mm
- Kerb weight
- 1,855 kg
- Max weight
- 2,450 kg
- Boot space (min)
- 500 l
- Boot space (max)
- 500 l
Wheels, brakes and chassis
- Tyre size
- 225/60/R16
- Optional tyre sizes
- 225/55R17, 245/45R18, 245/45R18 / 265/40R18
- Wheel fitment (PCD, CB)
- DIA66.6 5x112
- Front brakes
- Ventilated discs
- Rear brakes
- Ventilated discs
- Front suspension
- Independent, air suspension
- Rear suspension
- Independent, air suspension
