Mercedes-Benz S class IV (W220) Facelift Sedan Long All photos (5)
Mercedes-Benz S class IV (W220) Facelift · Sedan Long · 2002–2006

Mercedes-Benz S class 280 Long 2.8 AT 204 HP

GasolineAutomatic, 5 gearsRear drive
Power
204 hp · 150 kW
Torque
270 Nm
0–100 km/h
9.5 s
Top speed
230 km/h
Fuel consumption
11.5 l/100 km
On a full tank
~770 km
Other versions of this body · 8
280 Long 2.8 AT 204 HP 350 Long 3.7 AT 245 HP 350 Long 3.7 AT 245 HP AWD 430 Long 4.3 AT 279 HP 430 Long 4.3 AT 279 HP AWD 500 Long 5.0 AT 306 HP All versions →

Consumption and performance

manufacturer data
Top speed
230 km/h
Acceleration 0–100 km/h
9.5 s
Fuel tank
88 l

Engine

M112.922 · 2,799 cm³
Engine type
Gasoline
Engine code
M112.922
Displacement
2,799 cm³
Max power
150 kW / 204 hp
Torque
270 Nm at 3000 rpm
Fuel
A95
Fuel system
Multipoint injection
Turbo
No
Engine position
In front
Cylinders
6
Valves per cylinder
3
Valvetrain
SOHC
Bore
89.9 mm
Stroke
73.5 mm
Compression ratio
10

Transmission

Drive
Rear
Gearbox
Automatic
Gears
5

Dimensions and capacity

Body code W220 · class F
Body type
Sedan
Doors
4
Seats
5
Length
5,164 mm
Width
1,855 mm
Height
1,448 mm
Wheelbase
3,085 mm
Front track
1,575 mm
Rear track
1,575 mm
Ground clearance
150 mm
Kerb weight
1,770 kg
Max weight
2,300 kg
Boot space (min)
500 l
Boot space (max)
500 l

Wheels, brakes and chassis

Tyre size
225/60/R16
Optional tyre sizes
225/55R17, 245/45R18, 245/45R18 / 265/40R18
Rim size
7.5j
Wheel fitment (PCD, CB)
DIA66.6 5x112
Front brakes
Ventilated discs
Rear brakes
Discs
Front suspension
Independent, air suspension
Rear suspension
Independent, coil spring
