Mercedes-Benz R class I Facelift 2 Minivan Long All photos (17)
Mercedes-Benz R class I Facelift 2 · Minivan Long · 2010–2017

Mercedes-Benz R class 500 Long 5.5 AT 388 HP AWD

GasolineAutomatic, 7 gearsAll driveEuro 5
Power
388 hp · 285 kW
Torque
530 Nm
0–100 km/h
6.3 s
Top speed
250 km/h
Fuel consumption
13.2 l/100 km
On a full tank
~610 km
Other versions of this body · 8
300 Long 3.0 AT 231 HP 300 Long 3.0 AT 231 HP AWD 350 Long 3.0 AT 265 HP AWD 350 Long 3.5 AT 272 HP 350 Long 3.5 AT 272 HP AWD 500 Long 5.5 AT 388 HP AWD All versions →

Consumption and performance

manufacturer data
Top speed
250 km/h
Acceleration 0–100 km/h
6.3 s
Fuel tank
80 l

Engine

m273.963 · 5,461 cm³
Engine type
Gasoline
Engine code
m273.963
Displacement
5,461 cm³
Max power
285 kW / 388 hp
Torque
530 Nm at 2800 rpm
Fuel
A98
Fuel system
Direct injection
Turbo
No
Engine position
V type
Cylinders
8
Valves per cylinder
4
Valvetrain
DOHC
Bore
98 mm
Stroke
90.5 mm
Compression ratio
10.7
Emission standard
Euro 5
CO₂ emissions
235 g/km

Transmission

Drive
All
Gearbox
Automatic
Gears
7

Dimensions and capacity

Body code W251 · class M
Body type
Minivan
Doors
5
Seats
5, 7
Length
5,157 mm
Width
2,183 mm
Height
1,674 mm
Wheelbase
3,215 mm
Front track
1,661 mm
Rear track
1,651 mm
Ground clearance
170 mm
Kerb weight
2,265 kg
Max weight
2,920 kg
Boot space (min)
1,118 l
Boot space (max)
1,118 l

Wheels, brakes and chassis

Tyre size
255/50/R19
Optional tyre sizes
255/50R19 / 285/45R19, 265/45R20
Wheel fitment (PCD, CB)
DIA66.6 5x112
Wheel fasteners
Bolts M14x1.5
Tyre pressure
2.2-2.5 bar
Front brakes
Ventilated discs
Rear brakes
Discs
Front suspension
Independent, coil spring
Rear suspension
Independent, air suspension
