Mercedes-Benz G class II (W463) SUV 5 doors All photos (3)
Mercedes-Benz G class II (W463) · SUV 5 doors · 1990–2006

Mercedes-Benz G class 500 Euro 2 5.0 AT 296 HP AWD

GasolineAutomatic, 5 gearsAll driveEuro 2
Power
296 hp · 218 kW
Torque
456 Nm
0–100 km/h
7.7 s
Top speed
195 km/h
Fuel consumption
17.7 l/100 km
On a full tank
~540 km
Other versions of this body · 21
350 3.4 AT 136 HP AWD 400 4.0 AT 250 HP AWD 500 5.0 AT 241 HP AWD 5.0 AT 296 HP AWD 500 5.0 AT 296 HP AWD 500 Euro 2 5.0 AT 296 HP AWD All versions →

Consumption and performance

manufacturer data
Top speed
195 km/h
Acceleration 0–100 km/h
7.7 s
Fuel tank
96 l

Engine

M113.962 · 4,966 cm³
Engine type
Gasoline
Engine code
M113.962
Displacement
4,966 cm³
Max power
218 kW / 296 hp
Torque
456 Nm at 2800 rpm
Fuel
A95
Fuel system
Multipoint injection
Turbo
No
Engine position
V type
Cylinders
8
Valves per cylinder
3
Valvetrain
DOHC
Bore
97 mm
Stroke
84 mm
Compression ratio
10
Emission standard
Euro 2

Transmission

Drive
All
Gearbox
Automatic
Gears
5

Dimensions and capacity

Body code W463 · class J
Body type
SUV
Doors
5
Seats
5, 7
Length
4,680 mm
Width
1,760 mm
Height
1,935 mm
Wheelbase
2,850 mm
Front track
1,475 mm
Rear track
1,475 mm
Ground clearance
220 mm
Kerb weight
2,395 kg
Max weight
3,500 kg
Boot space (min)
480 l
Boot space (max)
2,250 l

Wheels, brakes and chassis

Tyre size
255/65/R16
Wheel fitment (PCD, CB)
DIA84.1 5x130
Front brakes
Ventilated discs
Rear brakes
Discs
Rear suspension
Independent, coil spring
