Mercedes-Benz G class II (W463) Facelift 1 SUV 3 doors All photos (5)
Mercedes-Benz G class II (W463) Facelift 1 · SUV 3 doors · 2006–2008

Mercedes-Benz G class 320 3.0 AT 224 HP AWD

DieselAutomatic, 7 gearsAll drive
Power
224 hp · 165 kW
Torque
440 Nm
0–100 km/h
9.1 s
Top speed
177 km/h
Fuel consumption
11.0 l/100 km
On a full tank
~870 km
Other versions of this body · 4
320 3.0 AT 224 HP AWD 320 3.2 AT 215 HP AWD 500 5.0 AT 296 HP AWD 500 5.5 AT 388 HP AWD

Consumption and performance

manufacturer data
Top speed
177 km/h
Acceleration 0–100 km/h
9.1 s
Fuel tank
96 l

Engine

om642 · 2,987 cm³
Engine type
Diesel
Engine code
om642
Displacement
2,987 cm³
Max power
165 kW / 224 hp
Torque
440 Nm at 1600 rpm
Fuel system
Diesel, Common rail
Turbo
Turbo
Engine position
V type
Cylinders
6
Valves per cylinder
4
Valvetrain
DOHC
Bore
83 mm
Stroke
92 mm
Compression ratio
17.7

Transmission

Drive
All
Gearbox
Automatic
Gears
7

Dimensions and capacity

Body code W463 · class J
Body type
SUV
Doors
3
Seats
5
Length
4,212 mm
Width
1,760 mm
Height
1,931 mm
Wheelbase
2,400 mm
Front track
1,475 mm
Rear track
1,475 mm
Ground clearance
220 mm
Kerb weight
2,750 kg
Max weight
2,870 kg
Boot space (min)
250 l
Boot space (max)
1,580 l

Wheels, brakes and chassis

Tyre size
255/65/R16
Front brakes
Discs
Rear brakes
Discs
Rear suspension
Independent, coil spring
