Ford Transit Connect II Facelift · Van LWB · 2018–2024
Ford Transit Connect LWB 1.5 MT 75 HP
- Power
- 116 hp · 85 kW
- Torque
- 170 Nm
- 0–100 km/h
- 10.5 s
- Top speed
- 195 km/h
- Fuel consumption
- 8.0 l/100 km
- On a full tank
- ~650 km
Other versions of this body · 7
Consumption and performance
- Top speed
- 195 km/h
- Acceleration 0–100 km/h
- 10.5 s
- Fuel tank
- 52 l
Engine
- Engine type
- Gasoline
- Engine code
- x18xe1
- Displacement
- 1,796 cm³
- Max power
- 85 kW / 116 hp
- Torque
- 170 Nm at 3400 rpm
- Fuel
- A95
- Fuel system
- Multipoint injection
- Turbo
- No
- Engine position
- In front
- Cylinders
- 4
- Valves per cylinder
- 4
- Valvetrain
- DOHC
- Bore
- 80.5 mm
- Stroke
- 88.2 mm
- Compression ratio
- 10.5
Transmission
- Drive
- Front
- Gearbox
- Manual
- Gears
- 5
Dimensions and capacity
- Body type
- Estate (wagon)
- Doors
- 5
- Seats
- 5
- Length
- 4,288 mm
- Width
- 1,710 mm
- Height
- 1,465 mm
- Wheelbase
- 2,611 mm
- Front track
- 1,464 mm
- Rear track
- 1,452 mm
- Ground clearance
- 130 mm
- Kerb weight
- 1,200 kg
- Max weight
- 1,750 kg
- Boot space (min)
- 460 l
- Boot space (max)
- 1,500 l
Wheels, brakes and chassis
- Tyre size
- 195/60/R15
- Optional tyre sizes
- 215/45R17
- Rim size
- 5.5j x 15
- Wheel fitment (PCD, CB)
- DIA65.1 5x110
- Front brakes
- Ventilated discs
- Rear brakes
- Discs
- Front suspension
- Independent, coil spring
- Rear suspension
- Semi-independent, coil spring
