Daihatsu Cast I I Hatchback 5 doors All photos (4)
Daihatsu Cast I I · Hatchback 5 doors · 2015–2023

Daihatsu Cast I 0.7 52 HP AWD

DieselManual, 5 gearsFront drive
Power
71 hp · 52 kW
Torque
128 Nm
0–100 km/h
16.9 s
Top speed
168 km/h
Fuel consumption
6.5 l/100 km
On a full tank
~850 km
Other versions of this body · 4
0.7 52 HP 0.7 52 HP AWD 0.7 64 HP 0.7 64 HP AWD

Consumption and performance

manufacturer data
Top speed
168 km/h
Acceleration 0–100 km/h
16.9 s
Fuel tank
55 l

Engine

RF1G · 1,998 cm³
Engine type
Diesel
Engine code
RF1G
Displacement
1,998 cm³
Max power
52 kW / 71 hp
Torque
128 Nm at 3000 rpm
Fuel system
Diesel
Turbo
No
Engine position
In front
Cylinders
4
Valves per cylinder
2
Valvetrain
SOHC
Bore
86 mm
Stroke
86 mm
Compression ratio
21.7

Transmission

Drive
Front
Gearbox
Manual
Gears
5

Dimensions and capacity

Body code BJ · class C
Body type
Hatchback
Doors
5
Seats
5
Length
4,340 mm
Width
1,695 mm
Height
1,355 mm
Wheelbase
2,605 mm
Front track
1,460 mm
Rear track
1,460 mm
Ground clearance
140 mm
Kerb weight
1,150 kg
Max weight
1,695 kg
Boot space (min)
1,200 l
Boot space (max)
356 l

Wheels, brakes and chassis

Tyre size
205/50/R16
Optional tyre sizes
175/70R14, 195/50R16, 195/55R15
Wheel fitment (PCD, CB)
DIA54.1 4x100
Wheel fasteners
Nuts M12x1.5
Wheel tightening torque
90-120 Nm
Tyre pressure
2.1 bar
Front brakes
Discs
Rear brakes
Discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
