Chevrolet Equinox II SUV 5 doors All photos (8)
Chevrolet Equinox II · SUV 5 doors · 2009–2015

Chevrolet Equinox 2.4 AT 182 HP AWD

GasolineVariatorFront driveEuro 4
Power
146 hp · 107 kW
Torque
196 Nm
0–100 km/h
11.5 s
Top speed
190 km/h
Fuel consumption
7.5 l/100 km
On a full tank
~840 km
Other versions of this body · 6
2.4 AT 182 HP 2.4 AT 182 HP AWD 3.0 AT 264 HP 3.0 AT 264 HP AWD 3.6 AT 301 HP 3.6 AT 301 HP AWD

Consumption and performance

manufacturer data
Top speed
190 km/h
Acceleration 0–100 km/h
11.5 s
Fuel tank
63 l

Engine

4B11 · 1,998 cm³
Engine type
Gasoline
Engine code
4B11
Displacement
1,998 cm³
Max power
107 kW / 146 hp
Torque
196 Nm at 4200 rpm
Fuel
A92
Fuel system
Multipoint injection
Turbo
No
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
86 mm
Stroke
86 mm
Compression ratio
10
Emission standard
Euro 4

Transmission

Drive
Front
Gearbox
Variator

Dimensions and capacity

Body code GF2W · class J
Body type
SUV
Doors
5
Seats
5
Length
4,655 mm
Width
1,800 mm
Height
1,680 mm
Wheelbase
2,670 mm
Front track
1,540 mm
Rear track
1,540 mm
Ground clearance
215 mm
Kerb weight
1,415 kg
Max weight
1,985 kg
Boot space (min)
591 l
Boot space (max)
1,754 l

Wheels, brakes and chassis

Tyre size
215/70/R16
Optional tyre sizes
225/55R18
Wheel fitment (PCD, CB)
DIA67.1 5x114.3
Wheel fasteners
Nuts M12x1.5
Tyre pressure
2.3-2.4 bar
Front brakes
Ventilated discs
Rear brakes
Ventilated discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
