Chevrolet Captiva I Facelift 3 SUV 5 doors All photos (8)
Chevrolet Captiva I Facelift 3 · SUV 5 doors · 2015–2018

Chevrolet Captiva 2.4 MT 167 HP

DieselManual, 6 gearsFront driveEuro 6
Power
170 hp · 125 kW
Torque
400 Nm
0–100 km/h
9.2 s
Top speed
220 km/h
Fuel consumption
5.5 l/100 km
On a full tank
~1,130 km
Other versions of this body · 7
2.0 AT 163 HP AWD 2.4 AT 167 HP 2.4 AT 167 HP AWD 2.4 MT 167 HP 2.4 MT 167 HP AWD 3.0 AT 249 HP AWD All versions →

Consumption and performance

manufacturer data
Top speed
220 km/h
Acceleration 0–100 km/h
9.2 s
Fuel tank
62 l

Engine

B20DHT · 1,956 cm³
Engine type
Diesel
Engine code
B20DHT
Displacement
1,956 cm³
Max power
125 kW / 170 hp
Torque
400 Nm at 1750 rpm
Fuel system
Diesel, Common rail
Turbo
Turbo
Engine position
In front
Cylinders
4
Valves per cylinder
4
Valvetrain
DOHC
Bore
83 mm
Stroke
90 mm
Compression ratio
16.5
Emission standard
Euro 6
CO₂ emissions
145 g/km

Transmission

Drive
Front
Gearbox
Manual
Gears
6

Dimensions and capacity

class D
Body type
Estate (wagon)
Doors
5
Seats
5
Length
5,004 mm
Width
1,871 mm
Width incl. mirrors
2,093 mm
Height
1,525 mm
Wheelbase
2,829 mm
Front track
1,607 mm
Rear track
1,610 mm
Ground clearance
160 mm
Kerb weight
1,666 kg
Max weight
2,240 kg
Boot space (min)
560 l
Boot space (max)
1,665 l
Turning circle
11.7 m

Wheels, brakes and chassis

Optional tyre sizes
245/40R19, 245/45R18, 255/40R19, 255/45R18
Wheel fitment (PCD, CB)
DIA70.2 5x115
Front brakes
Ventilated discs
Rear brakes
Discs
Front suspension
Independent, coil spring
Rear suspension
Independent, coil spring
