Toyota Corolla Levin IV (AE85/AE86) · Coupe · 1983–1987
Toyota Corolla Levin 1.6 AT 130 HP
- Power
- 130 hp · 96 kW
- Torque
- 149 Nm
Consumption and performance
- Fuel tank
- 50 l
Engine
- Engine type
- Gasoline
- Engine code
- 4a-geu
- Displacement
- 1,587 cm³
- Max power
- 96 kW / 130 hp
- Torque
- 149 Nm at 5200 rpm
- Fuel
- A95
- Fuel system
- Multipoint injection
- Turbo
- No
- Engine position
- In front
- Cylinders
- 4
- Valves per cylinder
- 4
- Valvetrain
- DOHC
- Bore
- 81 mm
- Stroke
- 77 mm
- Compression ratio
- 9.4
Transmission
- Drive
- Rear
- Gearbox
- Automatic
- Gears
- 4
Dimensions and capacity
- Body type
- Coupe
- Doors
- 2
- Seats
- 5
- Length
- 4,205 mm
- Width
- 1,625 mm
- Height
- 1,335 mm
- Wheelbase
- 2,400 mm
- Front track
- 1,355 mm
- Rear track
- 1,345 mm
- Ground clearance
- 150 mm
- Kerb weight
- 930 kg
- Turning circle
- 9.6 m
Wheels, brakes and chassis
- Tyre size
- 185/70/R13
- Optional tyre sizes
- 195/60R14
- Wheel fitment (PCD, CB)
- DIA54.1 4x100
- Front brakes
- Discs
- Rear brakes
- Drums
- Front suspension
- Independent, coil spring
